Titanium sheet and plate are commonly used in manufacturing today, with the most popular grades being 2 and 5. Grade 2 is the commercially pure titanium used in most of the chemical processing plants and is cold formable. Grade 2 plate and sheet can have ultimate tensile strength at and above 40,000 psi. Grade 5 is the aerospace grade and is not cold formable, so it is used more often when no forming is needed. Grade 5 aerospace alloy will have ultimate tensile strength at and above 120,000 psi. AVAILABLE SPECIFICATIONS AMS-4911, 4907,4905, MIL-T-9046, ASTM-F136, DMS-1592, GM-3103,12TM-B265, AMS-4919, DMS-2275, AMS-T-9046, GM-3104, B50TF21, AMS-4918, DMS-1879, AMS-4909, 4910, AMS-4915, 4916, DMS-1784, AMS-4900, 4902, DMS-1536, ASTM-B265, AMS-4914 EXAMPLE APPLICATIONS Fire wall, driver protection, valve covers, bell housings, driveshaft tunnels, brake backing plates, heat shields, rocker shaft stands, jewelry
Titanium sheet and plate are commonly used in manufacturing today, with the most popular grades being 2 and 5.
Grade 2 is the commercially pure titanium used in most of the chemical processing plants and is cold formable. Grade 2 plate and sheet can have ultimate tensile strength at and above 40,000 psi.
Grade 5 is the aerospace grade and is not cold formable, so it is used more often when no forming is needed. Grade 5 aerospace alloy will have ultimate tensile strength at and above 120,000 psi.
AVAILABLE SPECIFICATIONS
AMS-4911, 4907,4905, MIL-T-9046, ASTM-F136, DMS-1592, GM-3103,12TM-B265, AMS-4919, DMS-2275, AMS-T-9046, GM-3104, B50TF21, AMS-4918, DMS-1879, AMS-4909, 4910, AMS-4915, 4916, DMS-1784, AMS-4900, 4902, DMS-1536, ASTM-B265, AMS-4914
EXAMPLE APPLICATIONS
Fire wall, driver protection, valve covers, bell housings, driveshaft tunnels, brake backing plates, heat shields, rocker shaft stands, jewelry
| ltem | Titanium plate, Titanium sheet |
| Grade | GR1,GR2,GR3,GR4,GR5,GR7,GR9,GR11,GR12,GR23,etc. |
| Size | 0.5-100mm,W/L(as required) or customizable |
| Standard | ASTM B265,ASTM F136,AMS 4900,AMS 4901,AMS 4911,AMS 4919,AMS 4914 |
| Quality and test | Hardness test,Bending test,Hydrostatic etc. |
| Application | Industrial, Aerospace, Petrochemical, Medical etc. |
| Feature | High strength, Corrosion resistance, High performance |
| Technics | Hot rolled,Cold Rolled |
| Surface | Bright, Polished, Pickling, Sandblasting |
| Processing Service | Bending, Welding, Decoiling, Cutting, Punching |
| Package | Wooden Box |
National military standard: GJB 9001C-2017
Aviation small and medium structural parts: BSENISO 9001:2015 EN9100:2018
American standard: ASTM B348, ASTM B381, AMS4928
Grade: GR1 GR2 GR3 GR4 GR5 GR7GR11 GR12 GR23
National standard: GB/T19001-2016/ISO 9001:2015
GB/T16598, GB/T25137, GJB2744A
Grade: TA1 TA2 TA3 TA9 TA10, TC4, TC4ELI, TC6, TC9, TC11, TA5, TA15, TC4, TC6, TC11, TC18, TC20
Medical American standard: ASTMF136
General: ASTM B265
Titanium sheet and plate are commonly used in manufacturing today, with the most popular grades being 2 and 5.
Grade 2 is the commercially pure titanium used in most of the chemical processing plants and is cold formable. Grade 2 plate and sheet can have ultimate tensile strength at and above 40,000 psi.
Grade 5 is the aerospace grade and is not cold formable, so it is used more often when no forming is needed. Grade 5 aerospace alloy will have ultimate tensile strength at and above 120,000 psi.
AVAILABLE SPECIFICATIONS
AMS-4911, 4907,4905, MIL-T-9046, ASTM-F136, DMS-1592, GM-3103,12TM-B265, AMS-4919, DMS-2275, AMS-T-9046, GM-3104, B50TF21, AMS-4918, DMS-1879, AMS-4909, 4910, AMS-4915, 4916, DMS-1784, AMS-4900, 4902, DMS-1536, ASTM-B265, AMS-4914
EXAMPLE APPLICATIONS
Fire wall, driver protection, valve covers, bell housings, driveshaft tunnels, brake backing plates, heat shields, rocker shaft stands, jewelry
| ltem | Titanium plate, Titanium sheet |
| Grade | GR1,GR2,GR3,GR4,GR5,GR7,GR9,GR11,GR12,GR23,etc. |
| Size | 0.5-100mm,W/L(as required) or customizable |
| Standard | ASTM B265,ASTM F136,AMS 4900,AMS 4901,AMS 4911,AMS 4919,AMS 4914 |
| Quality and test | Hardness test,Bending test,Hydrostatic etc. |
| Application | Industrial, Aerospace, Petrochemical, Medical etc. |
| Feature | High strength, Corrosion resistance, High performance |
| Technics | Hot rolled,Cold Rolled |
| Surface | Bright, Polished, Pickling, Sandblasting |
| Processing Service | Bending, Welding, Decoiling, Cutting, Punching |
| Package | Wooden Box |
National military standard: GJB 9001C-2017
Aviation small and medium structural parts: BSENISO 9001:2015 EN9100:2018
American standard: ASTM B348, ASTM B381, AMS4928
Grade: GR1 GR2 GR3 GR4 GR5 GR7GR11 GR12 GR23
National standard: GB/T19001-2016/ISO 9001:2015
GB/T16598, GB/T25137, GJB2744A
Grade: TA1 TA2 TA3 TA9 TA10, TC4, TC4ELI, TC6, TC9, TC11, TA5, TA15, TC4, TC6, TC11, TC18, TC20
Medical American standard: ASTMF136
General: ASTM B265
